CoreStation CS40

Suprema CoreStation is an intelligent door controller which provides the advantages of a biometric-enabled security over a centralized access control system. Designed to accommodate enterprise-level systems, the CoreStation can store up to 500,000 users with an incredible fingerprint matching speed of up to 400,000 match/sec. With its high-performance, biometric readiness, Ethernet communication, CoreStation is also capable of offering the full features of the BioStar 2 platform.

Features

Centralized Biometric Access Control

Centralized storage for user and access control data including fingerprint credentials

Complete controller functionalities with fingerprint matching

Multi-port interface for fingerprint /RF readers

Supports locks, sensors, RTE, and alarms

Improved Security

Centralized, secure storage of biometric and group access data
No Ethernet connection to the edge devices
No data stored on the edge devices
Secure communication via TLS 1.2
AES-256 encryption

System Flexibility and Scalability

Compatible with OSDP 2.0
Elevator control with OM-120
Supports up to 132 access points with DM-20 and Secure I/O 2
(132 x Wiegand readers/64 x RS-485 readers)
3rd party Wiegand reader
4ch onboard reader control
(Wiegand, RS-485, relays, inputs, outputs, power out, AUX)
Leverages existing wiring

Simultaneous matching speed up to 8 devices in 1 second

Configuration

Specification

Scroll left/right

Model Name

Capacity

Max. User
Max. Credential (1:N)
Max. Credential (1:1)
Max. Text Log
Max. Image Log

General

CPU
Memory
Crypto Chip
Display
LED
Sound
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Weight
Dimension (WxHxD, mm)
Certifications

Interface

Ethernet
Wi-Fi
Network Protocol
RS-485
RS-485 Communication Protocol
Wiegand
Input
Relay
USB
SD Card
PoE
Intercom
Supervised Input
Output
AUX Input
Tamper

Electrical

Power

Connectivity

Max. Slave Devices (RS-485)
Max. Wiegand Devices

CS-40

500,000¹⁾

Fingerprint: 100,000²⁾
Face: 4,000³⁾

Fingerprint: 500,000²⁾ / Face: 30,000³⁾
Card: 500,000 / PIN: 500,000

5,000,000

Not supported

1.4 GHz Octa Core

8GB Flash + 1GB RAM

Supported

Not supported

Multi-color

Not supported

0°C ~ 50°C (32°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 95%, non-condensing

415 g

150 x 214 x 21

CE, UKCA, KC, FCC, RCM, RoHS, REACH, WEEE, ETL Listed to UL 294

Support (10/100 Mbps, Auto MDI/MDI-X)

Not supported

TCP, UDP

5 ch

OSDP V2 Compliant

4 ch

8 ch (TTL Input or Supervised Input selectable)

4 relays

Not supported

8 ch (TTL Input or Supervised Input selectable)

8 ch

2 ch(AC POWER FAIL, TAMPER)

Optional (ENCR-10)

Voltage: 12 Vdc, Current: Max. 3 A

Max. 64 devices (Max. 31 devices per port)

Max. 132 devices (with DM-20)

¹⁾The number of users registered without any credential data.
²⁾FaceStation 2 and FaceLite are available only.
³⁾TTL Input or Supervised Input selectable.

• If CoreStation is a master device and a device with a fingerprint sensor is connected as a slave, the slave device can be used for fingerprint authentication.
- Max. Fingerprint Credentials (1:N): 100,000
- Max. Fingerprint Credentials (1:1): 500,000
