BioEntryW3

BioEntry W3 is an innovative facial authentication access control device powered by Suprema's advanced AI technology. Its AI processor, optimized with deep-learning (NPU), ensures high accuracy and lightning-fast facial processing speeds. Designed for both durability and resilience, BioEntry W3 withstands external impacts and extreme conditions, all while maintaining a slim and compact profile. Experience the future of security with a device that prioritizes secure private data, elegant simplicity, and lasting durability.

Secure Private Data —————

Front matter, or preliminaries, is the first section of a book and is usually the smallest section in terms of the number of pages. Each page is counted, but no folio or page number is expressed or printed, on either display pages or blank pages.

To produce perfect books, these rules have to be brought back to life and applied.

The device holds key certifications including ISO/IEC 27001, ISO/IEC 27701, which confirm its top-tier security in data protection.

Simple Design —————

BioEntry W3 features a minimalist design that is both visually appealing and sophisticated. Its clean lines and straightforward user experience eliminate unnecessary complexity. With its ultra-slim profile, BioEntry W3 seamlessly integrates into any environment, including mullion-type installations on door frames, where it fits perfectly without compromising aesthetics.

Durable Build —————

BioEntry W3 is durable and built to last. It can withstand prolonged use and tough conditions without losing its integrity or functionality.

Unmatched Performance —————

The Future of Securit

BioEntry W3 is highly efficient and effective in its functionality. It delivers strong, reliable performance, capable of handling demanding tasks with ease.

Enhanced User Experience

LED Screen Authentication: Verify identity via LED screen without exposing registered personal photos through an LCD, providing enhanced privacy protection.

Multi-Credential Support

Facial Authentication: Provides fast and accurate facial Authentication technology.
Mobile Access: Allows convenient access via smartphone.
Template on Mobile (ToM): Safely stores facial data on mobile devices for secure Authentication.
Various RFID Card Support: Supports a wide range of RFID cards for convenient use.

Innovative Facial Authentication Performance

FAS Algorithm Innovation: Delivers the best-in-class facial Authentication algorithm.
Advanced AI Technology: Enhances accuracy through AI training with over 500,000 facial Authentication data points.
Core Technology Optimization : Achieving top performance through the optimization of cameras and hardware for precise facial authentication data, along with software and proprietary algorithm optimization for data analysis.

High Quality & Over 20 Years of Trust

High Quality: Guaranteed superior quality
Over 20 Years of Trust: Products backed by more than 20 years of reliability
R&D and Made by Suprema in Korea

Specification

Scroll left/right

Model Name

Credential

Biometrics
RF Option
RF read range ²⁾
Mobile Card

Protections

IP rating
IK rating

Face

Authentication Distance ³⁾
Authentication Height
Matching speed
Live Face Detection

Capacity

Max. User
Max. Credential (1:N)
Max. Credential (1:1)
Max. Text Log
Max. Image Log

General

CPU
Memory
Crypto Chip
Display
Camera
LED
Sound
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Weight
Dimension (WxHxD, mm)
Certifications

Interface

Ethernet
Network Protocol
RS-485
RS-485 Communication Protocol
Wiegand
Input
Relay
USB
USB expansion port
PoE
RTSP
(Real Time Streaming Protocol)
Tamper

Electrical

Power

BEW3-DB

Face

125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa

MIFARE/DESFire/EM: 50 mm, FeliCa: 30 mm

NFC, BLE

IP67

IK08

0.3 ~ 1.0 m

1.4 ~ 1.9 m

Within 0.2 seconds

Supported

100,000⁴⁾

Face: 30,000
Card: 100,000

1,000,000

10,000

1.5 GHz Quad Core

16 GB Flash + 2 GB RAM

Supported

1.3” PMOLED

IR: 2M pixels
Visual: 2M pixels

Multi-color

16 bit

-20 °C ~ 50 °C

-40 °C ~ 70 °C

0 % ~ 80 %, non-condensing

0 % ~ 90 %, non-condensing

Device: 283 g
Bracket: 36 g

50 x 160 x 34.15 (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, ANATEL, SIG, RoHS, REACH, WEEE, EAC, TELEC

Supported (10/100 Mbps, auto MDI/MDI-X)

TCP, UDP

1 ch Master / Slave (Selectable)

OSDP V2 compliant

1 ch Input and 1 ch Output

3 ch Inputs

1 Relay

USB 2.0 (Type C), only FW-Upgrade

Supported

Not supported

Supported

Voltage: 12 Vdc, Current: Max. 1.0 A
Voltage: 24 Vdc, Current: Max. 0.6 A

BEW3-APB

Face

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, iCLASS SE/SR/Seos

MIFARE/DESFire/EM/iCLASS: 50 mm, FeliCa/HID Prox: 30 mm

NFC, BLE

IP67

IK08

0.3 ~ 1.0 m

1.4 ~ 1.9 m

Within 0.2 seconds

Supported

100,000⁴⁾

Face: 30,000
Card: 100,000

1,000,000

10,000

1.5 GHz Quad Core

16 GB Flash + 2 GB RAM

Supported

1.3” PMOLED

IR: 2M pixels
Visual: 2M pixels

Multi-color

16 bit

-20 °C ~ 50 °C

-40 °C ~ 70 °C

0 % ~ 80 %, non-condensing

0 % ~ 90 %, non-condensing

Device: 291 g
Bracket: 36 g

50 x 160 x 34.15 (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, ANATEL, SIG, RoHS, REACH, WEEE, EAC, TELEC

Supported (10/100 Mbps, auto MDI/MDI-X)

TCP, UDP

1 ch Master / Slave (Selectable)

OSDP V2 compliant

1 ch Input and 1 ch Output

3 ch Inputs

1 Relay

USB 2.0 (Type C), only FW-Upgrade

Supported

Supported (IEEE 802.3at compliant)

Supported

Voltage: 12 Vdc, Current: Max. 1.0 A
Voltage: 24 Vdc, Current: Max. 0.6 A
